Nontoxic Vermiculite Board For Stoves , Shockproof Refractory Insulation Plate

Ask Lasest Price
Model Number :	V-1100(700)
Supply Ability :	100000 Piece/Pieces per Month
Price :	$8.00/pieces 10-499 pieces
Brand Name :	Bluewind
Delivery Time :	15workdays

Add to Cart

Product Details
Company Profile

Nontoxic Vermiculite Board For Stoves , Shockproof Refractory Insulation Plate

Wood stove baffle board vermiculite fireproof board heat shock resistant panels

Product Description

Vermiculite board:1,100 C heat insulation and fireproof

Color: Silver

Material: Expanded silver vermiculite

Applying: Wood stoves, Fireplace, Heat Boiler, Melting furnace, Aluminum industry, Fire rated door 240 mins requirement etc.

Service: We offer small order with quantity 100 pcs standard board, and also customized board for order quantity over 100,000 sets. Costs accordingly to the exact requirement, and lead time quoted from the exact we need.

Product Name	Vermiculite board	Place of Origin	China
Brand	Hozu	Colour	Silver
Density	700 kgs/m3	Thickness	25 mm

Product Paramenters

Physical parameter
Density (kgs/m3)	700	800	900
Max temp.	1150 ℃	1150 ℃	1150 ℃
Strength	4.5/2.0 MPa	5.5/2.1 MPa	6.2/2.2 MPa
Linear shrinkage	1%	1%	1%
Thermal conduct.
@ 200 ℃	0.14 W/m.k	0.16 W/m.k	0.18 W/m.k
@ 400 ℃	0.16W/m.k	0.18 W/m.k	0.2 W/m.k
@ 600 ℃	0.18 W/m.k	0.2 W/m.k	0.22 W/m.k
Chemical parameter
SiO2	43-46 %	43-46 %	45-48 %
Al2O3	10-13 %	10-13 %	13-16 %
Fe2O3	4-6 %	4-6 %	4-6 %
TiO	1-2 %	1-2 %	1-2 %
MgO	16-23 %	16-23 %	14-20 %
K2O	7-10 %	7-10 %	5-8 %
Na2O	1-2 %	1-2 %	1-2 %
LOI @ 1000 C	4-6 %	4-6 %	3-5 %
Standard size & Thickness
1005*615 mm	10-60 mm thickness	10-60 mm thickness	10-60 mm thickness
1225*615 mm	10-60 mm thickness	10-60 mm thickness	10-60 mm thickness

Data are average results of tests conducted under standard precedures and are subject to variation.

Detailed Images

$Nontoxic Vermiculite Board For Stoves , Shockproof Refractory Insulation Plate$

High pressure pressing

bulk drying

$Nontoxic Vermiculite Board For Stoves , Shockproof Refractory Insulation Plate$

High quality standard requirement

Standard export packing

$Nontoxic Vermiculite Board For Stoves , Shockproof Refractory Insulation Plate$
